Modular Fixture Welding Table
Application:Welding&Assemble
Process:CNC Machining
Surface:Normal/Nitrided
Leg:Standard Legs/Castor wheel legs
Type:3D
Brand:Lemar
Products Description
Modular Fixture Welding Table is a system composed of a high-precision hole series platform and a set of modular, standardized fixture components. Its core concept is:
Through a few types of standardized, reusable modular components, and via countless combinations, it can quickly and accurately position, clamp, and weld workpieces of almost any shape.
Our address
505-1 NO.8 JIEFANG WEST ROAD,LIANGXI DISTRICT,WUXI,CHINA
Phone Number
+86 159 952 699 47
Evasummer@lemarmetal.com
Products Parameters
Products Specification
Example of Workflow
Suppose we need to weld a complex metal frame
Planning: Engineers use supporting software to design the placement and combination of all fixture components on the computer based on the 3D model.
Preparation: Workers receive the assembly drawings and take out the required components such as locating pins, stoppers, and clamps from the tool cart.
Installation: Fix the positioning components to the designated holes on the platform with bolts to establish the external boundaries and positioning datums of the workpiece.
Placing the workpiece: Place the parts to be welded on the set positioning components to ensure they are in place.
Clamping: Install and operate the clamping components to firmly fix the parts, ensuring they do not move during the welding process.
Welding: Perform the welding operation. Due to reliable clamping, welding deformation is smaller and precision is higher.
Disassembly: After welding is completed, loosen the clamps and take down the finished product.
Reassembly: Remove all used fixture components from the platform and put them back on the cart. The workbench returns to a blank state, ready for the clamping task of a completely different workpiece next time.
