T Head Bolts
Material:Steel
Head type:T- Head
Application:Building, Industry, Machinery
Products Description
What is T Head Bolts?
The bolt is common fasteners widely used in photovoltaic mounting systems. Its shape is similar to the English letter 'T', hence its name.
one-stop solution
professional team
high quality
Products Parameter
| T-BOLT | MODEL | A | B | C | D | E | F |
| EN30 | 30M6*16 | M6 | 16 | 4.8 | 15.6 | 7.9 | 2 |
| EN40 | 40M8*16 | M8 | 16 | 5.4 | 18 | 7.9 | 4 |
| 40M8*20 | M8 | 20 | 5.4 | 18 | 7.9 | 4 | |
| 40M8*25 | M8 | 25 | 5.4 | 18 | 7.9 | 4 | |
| 40M8*30 | M8 | 30 | 5.4 | 18 | 7.9 | 4 | |
| EN45 | 45M8*20 | M8 | 20 | 5.5 | 19 | 8.5 | 4.2 |
| 45M8*25 | M8 | 25 | 5.5 | 19 | 8.5 | 4.2 | |
| GB30 | 30M6*16 | M6 | 16 | 5 | 10 | 6 | 1.5 |
| 30M6*20 | M6 | 20 | 5 | 10 | 6 | 1.5 | |
| GB40 | 40M8*20 | M8 | 20 | 6 | 13.7 | 8 | 2 |
Products application
our casey
T Head Bolt is a special fastener for photovoltaic projects, with many uses, including but not limited to the use of solar support, paper machine fixing, hydraulic power generation and wind power generation fan installation.
The design features of the bolt enable it to be automatically positioned and locked during installation and is usually used in conjunction with flange nuts for applications requiring high strength, light weight and easy maintenance.
The material of T Head Bolt is mostly stainless steel, such as 304 or 316 material, to ensure its corrosion resistance and durability in a variety of environments.
In addition, in order to prevent rust, you can take plating, passivation treatment, storage in a dry and ventilated environment and apply anti-rust oil and other measures to protect the bolt, thereby extending its service life and maintaining its good anti-rust performance.
Products Features
Some knowledge about T head bolt
T head bolt is a bolt used in conjunction with a T-slot, also known as a T-bolt, whose head is the shape of a T-slot, directly into the T-slot, and is fixed through the screw thread connection.
During the installation process, it can be automatically positioned and locked, often used with flange nuts, and is a good helper for installing corner parts and other profile accessories.
The photovoltaic T-type bolt is mainly characterized by the fact that its head is in the shape of a parallelogram, and the four internal angles are not composed of right angles.
