Nitrided Universal Stop
Application:Welding&Assemble
Process:CNC Machining
Surface treatment:Normal/Nitrided
Type:3D
Brand:Lemar
Products Description
who choose us?
The nitrided Universal Stop is a core positioning accessory of the 3D flexible welding platform, used for precise workpiece positioning, repeatable alignment, and flexible clamping. The nitriding treatment endows it with high hardness, wear resistance, and deformation resistance.
Precision Positioning: Provides a fixed/adjustable reference stop surface for workpieces to ensure batch welding consistency.
Flexible Clamping: Compatible with D16/D28 welding tables, featuring a combination of long slots and round holes, suitable for workpieces of various sizes.
Wear-resistant and durable: Nitrided surface treatment offers high hardness, corrosion resistance, and resistance to deformation, making it suitable for heavy-duty welding applications.
one-stop solution
professional team
high quality
Product parameters
typical structure
-
Main body: Long strip alloy steel, thickness 12-25mm, width 30-50mm.
-
System holes: A row of D16/D28 standard holes (spaced 50mm apart) for fixed installation.
-
Long slot: 1 oval adjustment slot, providing 50-150mm travel for fine adjustment of positioning.
-
Precision Scale: Double sided etched fine scale for quick reading and repeated positioning.
-
Nitriding layer: surface plasma nitriding, hardness HV 800-1000, layer depth 0.3-0.5mm, wear-resistant and anti welding slag adhesion.
Common specifications
| Model | Length | Width | Thickness | Adjust the itinerary | Number of system holes |
| 80mm L | 80mm | 30mm | 12mm | 50mm | 1 hole+1 slot |
| 300mm M | 300mm | 50mm | 12mm | 100mm | 7 holes+1 slot |
| 500mm M | 500mm | 50mm | 12mm | 150mm | 13 holes+1 slot |
| 325mm L(S28) | 325mm | 50mm | 25mm | 100mm | 4 holes+1 slot |
If you need other customized sizes, please contact us for detailed information
Advantages of Nitrided Process
High hardness and wear resistance: The surface hardness far exceeds quenching, and it is not easy to wear or deform after long-term use, with long-lasting positioning accuracy.
Anti corrosion and anti sticking: The dense nitride layer prevents rust and welding slag adhesion, making it easy to clean and suitable for harsh welding environments.
Minimal deformation: Low temperature nitriding (≈ 500 ℃), no organized phase transformation, negligible heat treatment deformation, suitable for precision fixtures.
High fatigue strength: residual compressive stress on the surface, resistance to fatigue cracking, and resistance to repeated clamping impacts without easy damage.
Certificate of Product Quality
FAQ
Everything You Need to Know
Can it adjust positioning distance freely?
Yes. Equipped with elongated adjustment slot, you can fine-tune the position easily and lock firmly after adjustment.
Can it work with other welding jigs?
Yes. Equipped with elongated adjustment slot, you can fine-tune the position easily and lock firmly after adjustment.
What trade terms can you offer?
We support EXW, FOB, CIF, DDP and other international trade terms.
What is the warranty policy?
1 year normal use warranty, non-human damage quality problem supported after-sales solution.
Want to buy Nitrided Universal Stop?
Feel free to contact us for more details. We're always here to help you.
