3D Adjustable Welding Workbench

1. Workbench surface:
◦ Made of high-strength cast iron or steel to ensure flatness, stability, and no deformation.
◦ The surface is covered with grid holes arranged at standard intervals (such as 100mm x 100mm, 50mm x 50mm). These holes are precision-machined with high accuracy and consistency.
◦ The sides of the holes are usually also equipped with threaded holes for lateral connection.
2. Functional modules and fixture components:
◦ Locating pins/locating blocks: Used to determine the reference position of the workpiece.
◦ Clamps: Including quick-press arms, spiral clamps, etc., used to press the workpiece onto the table surface from above.
◦ Supports: Including support blocks and support columns of various heights, used to hold the workpiece in the Z-axis direction (height).
◦ Angle devices/squares: Used to ensure perpendicularity or specific angles between workpieces.
◦ Locking pins/bolts: Used to quickly and firmly lock all fixture components in the grid holes of the table surface.
3. Base/frame:
◦ A sturdy steel structure that provides stable support for the entire workbench, usually with adjustable feet for leveling.
