Steel Welding Bench
Material:Q355 Steel
Application:Welding&Assemble
Process:CNC Machining
Surface treatment:Nitrided
Type:3D D28
Size:1000*2000mm
Brand:Lemar
Contact Us:Eva(+8615995269947/Email:evasummer@lemarmetal.com)
Product Overview
Our steel welding bench, also known as 3D flexible welding platform, is engineered for high precision metal fabrication and welding assembly work. Built with high‑strength cast steel and subject to nitriding surface treatment, this modular workbench features a full hole grid system compatible with D28 and D16 fixture series. Various clamps, positioning angles and support blocks can be freely combined and installed on the bench surface. It eliminates repeated custom fixture production, shortens workpiece setup time and guarantees consistent assembly accuracy for small‑batch and multi‑variant welding jobs. The whole structure delivers outstanding rigidity and deformation resistance under long‑term welding thermal load, which makes it a core workstation for modern welding workshops.
Our address:505-1 NO.8 JIEFANG WEST ROAD,LIANGXI DISTRICT,WUXI,CHINA
Phone Number:+86 159 952 699 47(Eva Summer)
Products Parameters
Products Advantages
High‑precision nitrided surface
The working surface goes through strict nitriding treatment. High hardness effectively resists welding spatter scratch and wear, maintaining hole‑position accuracy for long‑time heavy‑duty operation.
Strong modular flexible combination
Standard grid hole design supports free assembly of all matching fixtures. Users can quickly adjust locating scheme for different workpieces without making dedicated jigs.
Excellent structural rigidity
Adopt thickened cast‑steel integral structure. Anti‑deformation performance avoids bench distortion caused by welding heat and heavy load, securing assembly dimension stability.
Wide compatibility
Two mainstream hole types D28 and D16 are available. Fit most common welding fixture parts in the market, convenient for spare‑part supplement and stock management.
Flexible installation and movement options
Equipped with adjustable support feet for horizontal fine tuning. Mobile caster legs are optional for workshop site transfer to meet different layout demands.
Cost saving for batch production
One set of bench serves multiple workpiece projects. It greatly cuts jig development cost and shortens workpiece clamping time, improving overall workshop working efficiency.
High Purity Q355 steel Material
Tougher and more resistant to use
In-stock goods
Source manufacturer with guaranteed production capacity
High precision fixtures
Made by CNC machine,16mm/28mm two systems are compatible.
Adjustable legs
4 types legs:standard legs/adjustable legs/caster wheel legs/square legs.
Product Applications
Heavy‑duty metal frame welding and assembly
Mechanical equipment frame manufacturing and positioning inspection
Automobile component welding fixture station
Engineering machinery part fabrication
Steel structure workshop custom assembly work
Educational training and technical research laboratory
Shipping & Packaging
FAQ
Q1:Can I get custom sizes for this steel welding bench?
A:Yes. We support non‑standard dimension customization. You can provide your required length width and load requirement for our technical team to make suitable solution.
Q2:What is the difference between D28 and D16 hole system?
A:D28 fits larger fixtures for heavy load workpieces. D16 is more suitable for light and medium‑size precise welding projects. You can select based on your workpiece weight and accuracy demand.
Q3:How long is the production lead time?
A:Standard models take about 15 working days. Custom‑size benches need 25‑30 working days according to drawing complexity. We will confirm exact schedule before order confirmation.
Q4:Will welding high temperature damage the bench surface?
A:The nitrided surface owns high heat‑resistance performance. Normal welding spatter will not cause permanent damage. We still suggest basic anti‑spatter protection during daily operation to extend service life.
Q5:What about packing and shipping method?
A:Products are packed in sturdy export wooden cases. We can offer multiple shipping solutions including sea freight air freight and railway transport according to your destination and delivery time requirement.
Q6:What level of flatness can I expect from the welding bench working surface?
A:Our nitrided steel welding bench is precision machined. The flatness tolerance is controlled within 0.1 mm per meter under standard ambient condition, which meets general industrial welding and assembly positioning requirements.
Welcome to contact us
If you have any technical questions, size consultation or quotation demand for our steel welding bench, please feel free to send us your inquiry. Our professional engineering team will reply to you promptly and provide targeted solution for your welding workshop. Look forward to establishing long‑term cooperative relationship with you.
