Robotic Welding Fixture Table
Application:Welding&Assemble
Process:CNC Machining
Surface treatment:Normal/Nitrided
Type:3D
Brand:Lemar
Product Overview
Our robotic welding fixture table is engineered to integrate seamlessly with automated welding cells for consistent high repeatability production. Built with precision machined hole grids, it delivers stable locating reference points for robotic torch movement. The rigid table structure minimizes deflection under cyclic clamping and welding heat load. It supports fast fixture reconfiguration to switch between different workpieces without heavy rework. Designed to pair with robot arms and automatic clamping systems, this table reduces manual positioning errors and raises the overall uptime of your robotic welding line. Every tabletop undergoes strict flatness inspection to meet the tight tolerance requirements of automated welding processes.
Specification Table
| Model No. | Table Dimension L×W (mm) | Hole Standard | Plate Thickness | Adjustable Height | Application Range |
|---|---|---|---|---|---|
| D16-1008 | 1000×800 | Φ16, 50mm pitch | 12mm | 750–850mm | Electronic soldering, small sheet metal, aluminum parts |
| D16-1210 | 1200×1000 | Φ16, 50mm pitch | 12mm | 750–850mm | Small cabinet, stainless steel workpiece brazing |
| D28-1510 | 1500×1000 | Φ28, 100mm pitch | 12mm | 750–850mm | Pipe frame, general metal structure welding |
| D28-2010 | 2000×1000 | Φ28, 100mm pitch | 25mm | 750–850mm | Auto accessories, warehouse rack welding |
| D28-2015 | 2000×1500 | Φ28, 100mm pitch | 25mm | 750–850mm | Large cabinet, robotic soldering workstation |
| D28-3015 | 3000×1500 | Φ28, 100mm pitch | 25mm | 750–850mm | Engineering machinery parts, heavy frames |
| D28-4020 | 4000×2000 | Φ28, 100mm pitch | 25mm | 750–850mm | Oversized steel structure, splicing assembly line |
core functionality
High Repeatability For Automated Welding
Precision hole positioning ensures every workpiece sits at the identical coordinate for the robot. It removes position drift and keeps weld quality consistent across large production batches.
Spatter Resistant Nitrided Tabletop
The hardened nitrided surface resists weld spatter adhesion and mechanical abrasion. Less frequent surface maintenance keeps the table's reference accuracy for longer running cycles.
Rigid Anti Deformation Frame Construction
Thickened support frame absorbs welding thermal stress and clamping force. It stays stable during long continuous robot operation and avoids coordinate offset for robotic programs.
Reduced Downtime In Mass Production
Reliable locating performance cuts frequent manual adjustment and inspection work. Your robotic welding system can run longer continuous cycles and improve daily production output.
Customer Feedback
Certification & Factory Inspection
packaging & Shipping
FAQ
Q1:Can this table work with different brands of welding robots?
Yes. It adopts universal modular positioning standards. It can cooperate with most mainstream robot brands as long as the fixture layout is properly designed.
Q2:Which hole size should I choose for robotic fixtures D16 suits smaller compact parts?
D28 offers stronger clamping force for heavy workpieces. We can give suggestions based on your part weight and welding process.
Q3:Is the table surface able to bear repeated high temperature welding cycles?
Yes. The nitrided layer and cast iron substrate resist thermal fatigue. We still recommend regular slag cleaning to protect the reference holes.
Q4:What tolerance can this table maintain after years of robot operation?
Under normal use and proper maintenance, the table can keep flatness within the specified tolerance range for long term automated production.
